The VGM14 is a compact analog mixer with onboard effects that builds on the PGM8 by offering more channels, more features, and a built-in 2-channel USB audio interface. It’s an all-in-one solution for live sound, installations, and presentations that require up to fourteen input channels (ten mono, two stereo).
It offers extended connectivity with twelve XLR mic inputs, ten mono 1/4" inputs, and two stereo 1/4" inputs. Hi-Z switches on channels 9 and 10 enable the direct connection of instrument-level signals such as a guitar or bass without requiring an external DI. Each channel has a switchable high-pass filter, mute and solo buttons, clip indicator, and 60 mm fader. Mono channels feature a 3-band EQ with a sweepable midrange frequency, and stereo channels feature 4-band EQ.
The 24-bit DSP engine has sixteen stereo effects including reverb, delay, modulation, and more. Channels 1 through 10 offer built-in compression and insert points, and a 9-band graphic EQ on the main output lets you fine-tune the total mix.
The VGM14 also includes multi-segment VU metering, phantom power, RCA connections to easily integrate consumer AV equipment, footswitch support to mute the onboard effects, a convenient global mute for input channels, a dedicated zone / subwoofer output, LED lamp connector, and independent control of main, monitor, and headphone levels.
Packed with features and intuitive to operate, we like to think the VGM14 is a very good mixer.
Features
- 10x Mono Channels (XLR / 1/4")
- 2x Stereo Channels (1x XLR, 2x 1/4")
- Global Phantom Power
- Selectable Hi-Z Instrument Input on Channels 9 and 10
- Onboard Compression on Channels 1 - 10
- Onboard Digital Effects with 16 Algorithms and Parameter Control
- 3-Band EQ per Channel with 9-Band Master Graphic EQ
- 60 mm Faders
- 2-Channel USB Audio Interface
Specifications
| Number of Channels |
14 |
| Channel Inserts |
10 |
| Channel EQ |
3-Band with Mid Sweep (Mono Channels)
4-Band (Stereo Channels) |
| Channel Overload Protection |
Yes |
| Inputs |
12x XLR
14x 1/4" TRS
1x Stereo RCA |
| Channel Features |
Gain, High-Pass Filter (80 Hz)
Monitor Send
Pre / Post Aux Send
EFX Send
Pan / Balance
Mute
Solo
Clip / Mute LED |
| Phantom Power |
Global 48 V with LED Indicator |
| VU Meter |
2x 10-Segment LED |
| Headphone Monitor Features |
1x 1/4" |
| Internal Effects |
16 Algorithms, 24-Bit Stereo with Parameter Control |
| Auxiliary Sends |
EFX (to Internal Effects and 1/4" EFX Send)
Aux (to 1/4" Aux Send) |
| Outputs |
1x RCA (Record Out)
1x USB (Media Out)
2x 1/4" TRS (Main Outs)
2x XLR (Main Outs)
1x 1/4" (Zone/Sub Out) |
| Master EQ -1 (type/Channels/Range -dB) |
9-Band Graphic |
| Mixer - Frequency Response |
20 Hz - 20 kHz |
| Mixer THD (Main out w/ -10dB input) |
<0.05% |
| CMRR AT 60Hz (min/typ) |
55 dB / 65 dB |
| Power Consumption (typ/max) |
26 VA |
| Cooling |
Fan |
| Transformer Type |
SMPS |
| Chassis Construction |
Steel |
| Console Lamp Connector 12V DC (BNC) |
12V DC (BNC) |
| Other Features |
Input Compressors (Channels 1 - 10)
Hi-Z Input Switch (Channels 9 - 10)
EFX Footswitch Jack
Zone / Sub Output
USB I/O |
| Dimensions (DWH inches) |
16" x 19" x 2.8" (40.6 cm x 48.3 cm x 7.1 cm) |
| Weight (lbs/kg) |
13 lbs / 5.9 kg |
Specifications subject to change without notice
