15 in. Bass Reflex Subwoofer
The VRX915S is a compact, high power suspendable subwoofer system containing a 2265G-1 neodymium magnet, patented Differential Drive®,, 15, woofer in a front-loaded, vented enclosure.
FEATURES
- Integral rigging hardware for simple connection of VRX915S line-arrays and optional array frame.
- 15 inch, 2265G-1 Differential Drive, woofer for extended low-frequency output.
- Light and compact for versatility and easy handleability.
- 20 mm threaded pole socket for solid, secure satellite speaker mounting.
APPLICATIONS
- Live performance systems.
- Mobile and fixed DJ systems.
- Sound system rental and tour.
- Permanent installations.
SPECIFICATIONS
|
Power Rating |
800 W / 1600 W / 3200 W |
|
Frequency Range |
35 Hz - 250 Hz (-10 dB) |
|
Dimensions
(H x W x D) |
496 mm x 420 mm x 597 mm
(19.5 in x 16.5 in x 23.5 in) |
|
Frequency Response |
40 Hz - 250 Hz (+/-3db) |
|
System Maximum SPL |
126 dB SPL |
|
System Sensitivity (1w @ 1m |
91 dB SPL |
|
LF Driver |
1 x JBL 2265G-1, 250 mm (15 in) Differential Drive®, woofer |
|
Nominal Impedance |
4 Ohms |
|
Active Tunings |
Tunings available at www.jblpro.com |
|
Enclosure |
15 mm - 18 mm, multi ply birch plywood |
|
Suspension / Mounting |
Top mounted M20 threaded socket for optional pole SS4-BK. Integrated flying hardware for use with array frame VRX-SMAF. 8 M10 fittings. Optional M10 eyebolt kit. |
|
Finish |
Black DuraFlex, finish |
|
Grille |
Power coated, black, 16-gauge perforated steel with with acoustically transparent black foam backing. |
|
Input Connectors |
Switchable, +1/-1 or +2/-2 |
|
Net Weight |
26.3 kg (58 lb) |
