Description
No matter where you want to record, your projects should always sound great. The UR22C brings you amazing sound quality in a remarkably compact, tough and versatile package for composing and recording anywhere. Use it with a computer or an iOS device for superb results, wherever you are.
Features
32-bit/192 kHz audio resolution
The industry-leading converters used in the UR-C series deliver exceptional audio quality, thanks
Superspeed USB 3.1 with USB-C
UR-C interfaces feature the USB 3.1 Gen 1 SuperSpeed standard, which provides fast, reliable and
Ultra-rugged build
Built to the most exacting standards, with a robust metal casing, the UR-Cs are rugged enough to
Latency-free monitoring with DSP effects
With built-in digital signal processing (DSP), UR-C interfaces provide zero latency monitoring
Class-A D-PRE mic preamps
The UR-C series features D-PRE preamps, offering stellar recording quality unmatched in this price
Compatible with all major audio software
Our UR-Cs are compatible with all major audio software supporting the ASIO, Core Audio or WDM
iOS ready via CC Mode
Combining UR-C units with an iOS audio application such as Steinberg’s Cubasis for iPad, provides
Loopback function for streaming
The Loopback function of the UR-Cs offers an easy way of streaming performances live to the
Included software
Cubase AI
Based on Steinberg’s award-winning advanced music production system Cubase Pro, Cubase AI is a
Cubasis LE
UR-C’s seamless integration with iPad is enhanced by the inclusion of Cubasis LE, for creating
dspMixFx mixing application
UR-C interfaces provide zero-latency monitoring with effects for every DAW, with straightforward
Included Effects
Bundled effects plug-in suite
UR-C interfaces come with VST 3, AU and AAX versions of the onboard DSP plug-ins, providing many
REV-X reverb
The REV-X built into UR-C interfaces is a complex reverb algorithm, renowned for its high-density
Sweet Spot Morphing Channel Strip
Developed to deliver a highly musical result, the Sweet Spot Morphing Channel Strip combines a
Guitar Amp Classics
Guitar Amp Classics are guitar amplifier effects that make extensive use of advanced Yamaha
Clean
Optimized for clean tones, this amp effectively simulates the tight brilliance of transistor
Crunch
This is the amp type to use when you want lightly overdriven crunch tones. It simulates the type
Drive
The DRIVE amp type provides a selection of distortion sounds that simulate the tonal character of
Lead
This amp type simulates a high gain tube amp that is rich in overtones. Ideally suited to playing
| Connection Type | USB Type-C |
|---|---|
| Design | Desktop (1/3 19“, 1HU) |
| Casing | Full-metal casing |
| Power supply | USB 3.0 bus-powered, USB Type-C bus-powered, External USB 5 V AC adaptor (not included) |
| AD/DA | 32 bit |
|---|---|
| Maximum sample rate | 192 kHz |
| Dynamic range input | 102 [dB] |
| Total number of inputs | 2 |
|---|---|
| Total number of indiviudal outputs | 2 |
| Total number of Outputs | 2 |
| Microphone preamp | D-PRE |
| Microphone inputs | 2 |
| Inputs with line level | 2 |
| Inputs with HI-Z | 1 |
| Analog inputs TRS | 0 |
| Analog inputs Combo | 2 |
| Analog outputs TRS | 2 |
| Phantom power | 2 |
| Headphone | With dedicated volume control |
| Headphones outputs | 1 |
| Digital In ADAT | 0 |
| Digital Out ADAT | 0 |
| Digital In S/PDIF Optical | 0 |
| Digital In AES/EBU RS422 | 0 |
| Digital Out S/PDIF Optical | 0 |
| Digital Out AES/EBU RS422 | 0 |
| MIDI I/O |
| Monitoring | Latency free monitoring with FX |
|---|---|
| Onboard DSP | SSP 3 |
| True Integrated Monitoring with FX in Cubase | |
| High-Pass filter | |
| REV-X Reverb | |
| Sweet Spot Morphing Channel Strip |
| Weight | 1000 g |
|---|---|
| Width | 159 mm |
| Height | 47 mm |
| Depth | 159 mm |
| Operating systems (Mac) | macOS Sierra, macOS High Sierra, macOS Mojave, macOS Catalina, macOS Big Sur |
|---|---|
| Operating systems (Windows) | Windows 7 (64-bit), Windows 8.1 (64-bit), Windows 10 (64-bit) |
| Operating systems (iOS) | iOS 10, iOS 11, iOS 12, iOS 13 |
| Port | USB Type-C, USB 3.0, USB 2.0 |
| CPU minimum | Intel Core i-series multicore processor 2 GHz or faster, or AMD equivalent processor |
| RAM minimum | 2 GB |
| Hard disk free space | 1200 MB |
| Display resolution recommended | 1280 x 800 |
| Internet connection for | account sign up and product registration, installer download, driver and tools, license activation, manuals and instructions, additional downloads |
