Description
Extensive controls enable customized performance.
To provide maximum versatility, the ULT18 offers several important user controls. Unlike most subwoofers in this class, the ULT18 features a variable lowpass filter that enables you to accurately dial in the crossover transition between the subwoofer and your full-range system. Two DSP presets provide extended low-frequency performance or a more natural response to suit a variety of applications, and of course you get polarity reverse. A Mono Mode function is also provided to simplify cabling multiple mono subs in a stereo system.
Equally at home in mobile and installed systems.
Like the full-range ULT12 and ULT15 loudspeakers, the ULT18 has a rugged, tour-grade birch enclosure for the distinctive performance characteristics that only wood can offer. A locking IEC power connector, M10 rigging points, integrated castor provisions, and ground-stacking provisions, making it a great choice for a wide variety of mobile and install applications. Two combo XLR and ¼-inch TRS line-level inputs with level control and throughputs are provided to connect full-range systems or multiple subwoofers in larger systems. As with the ULT12 and ULT15, you can defeat the front power-indicator LED for low-visibility installs.
Designed by WorxAudio.
ULT18 loudspeakers were designed by WorxAudio®, the commercial loudspeaker division of PreSonus. Headquartered in Greensboro, North Carolina, WorxAudio has been at the forefront of loudspeaker development for the pro touring and contractor markets for over 30 years. WorxAudio continues to embrace the latest technology, delivering innovative products and installation designs for professional clients, and their products can be found in prestigious facilities worldwide. So you can rely on ULT loudspeakers to deliver the top-quality professional performance and features that touring engineers and systems integrators need.
Now hear this.
With flexible connectivity; a rugged, tour-grade enclosure; and generous Class D power, the ULT18 delivers the versatility and punch expected from today’s professional sound systems and is an excellent solution for permanent installations. Yet it’s also portable, making it a top choice for tours and other mobile use. Although designed to complement ULT-series full-range loudspeakers, the ULT18 is also an excellent companion for third-party loudspeakers. Most important, it sounds great, delivering outstanding low-end clarity and natural music reproduction. Hear ULT-series loudspeakers for yourself at your favorite PreSonus dealer.
Six-year warranty lets you rest easy.
When you choose ULT or AIR loudspeakers, you choose confidence. Rest assured that your new PreSonus speakers are in it for the long haul. We take our build quality seriously, and if anything goes wrong with them in your first six years of ownership (assuming you don't throw them in a swamp or anything like that) the repair or replacement is on us.
Features
Main Components
- 18-inch custom woofer with 4-inch voice coil
- 7 mm driver travel before over-excursion
- 2,000W Class D power (2 × 500 W continuous)
- Stereo combo XLR and ¼-inch inputs with direct outputs
- Onboard fully variable lowpass filter lets you dial in upper frequency limit
Controls
- Output Level
- Lowpass Filter
- Preset Select
- Polarity Invert On/Off
- Mono On/Off
- Front LED On/Off
Convenience Features
- Defeatable front-panel LED
- Rugged, texture-painted eucalyptus plywood enclosures
- Tour-grade 16 gauge steel grille
- Comfortable ergonomic handles
- Ground-stacking provisions
- Integrated caster provisions (caster kit sold separately)
- Locking IEC connection
Technical Specifications
Acoustic Performance |
|
|---|---|
| Configuration | Powered subwoofer, ported |
| Frequency Response (-3 dB) | 42 Hz – 150 Hz (Variable) |
| Maximum Peak SPL | 135 dB |
| Crossover Frequency | 90 Hz |
| Low Pass Filter Range | 50 Hz - 150 Hz |
Transducer |
|
|---|---|
| LF Transducer | 1x18" Ferrite |
| Voice Coil Diameter | 4" |
Amplifier |
|
|---|---|
| Type | Class D |
| Total Power Output | 2,000W Peak (1,000 RMS) |
| LF Power | 2 x 500W bridged (1000W total) |
| Cooling | Free air convection |
| Rated THD | <0.05% (20 Hz - 20 kHz) |
| Dynamic Range | 119 dB (A-weighted) |
| Bandwidth | 20 Hz - 20 kHz |
Connections and Controls |
|
|---|---|
| Input Channels | 2 line |
| Input Connector Types | 2 combo |
| Line Input Impedance | 10 kΩ |
| Maximum Input | +22 dBu |
| Output Connector | 2 XLR (M): Mix out, Direct out |
| Controls | Output Level Low Pass Filter Preset Select Polarity Invert On/Off Mono On/Off Front LED On/Off |
| Indicators | DSP Preset, Polarity Invert On/Off, Mono On/Off, Front LED On/Off, Signal, Clip, Thermal |
DSP |
|
|---|---|
| Presets | Extended LF |
| Polarity | Normal or Reverse |
| Bit Depth | 24-bit |
| Sample Rate | 96 kHz |
Enclosure |
|
|---|---|
| Material | Eucalyptus plywood |
| Finish | Chemline™ polyurethane |
| Grille | Powder-coated steel |
| Dimensions (HxWxD) | 22.5” x 25” x 24.5” (572 mm x 635 mm x 622 mm) |
| Unit Weight | 95 lbs. (43 kg) |
| Handles | 2 (one on each side) |
Safety |
|
|---|---|
| Amplifier Protection | Over-current, DC, over/under-voltage, over-temperature, high frequency |
| Transducer Protection | limiter |
Power |
|
|---|---|
| AC Power Input | 100-230V~, 50-60 Hz |
| AC Power Consumption (1/8 Power) | 150W |
Suspension Mounting |
|
|---|---|
| Rigging Points | 12 M10 |
| Mounting | Ground-stack provisions |
