Wireless Handheld Transmitter with BETA87C Microphone.
The ULXD2 VHF Handheld Transmitter with Beta 87C Microphone Capsule from Shure is designed for compatibility with Shure's ULX-D wireless systems. It has an interchangeable cardioid Beta 87C capsule and is set to Shure's V50 frequency band that operates between 174 to 216 MHz.
The ULXD2 has AES 256-bit encryption that keeps your signal secure. Featuring Shure's proprietary Gain Ranging, the ULXD2's dynamic range is optimized based on the input source and eliminates the need for transmitter gain adjustments. It has a lightweight, 12-ounce metal body with a backlit LCD menu with frequency and power lockout to avoid accidental setting changes. Powered by two AA batteries or the optional SB900 rechargeable battery pack, the ULXD2 has external charging contacts and is compatible with SBC200 dual docking charger.
SPECIFICATIONS
- Type Electret Condenser
- Frequency Response 50 Hz to 16 kHz
- Polar Pattern Cardioid
- Sensitivity -51 dBV/Pa (2 mV), 1 Pascal=94 dB SPL @ 1kHz, @ 1 kHz, open circuit voltage
- Maximum SPL 139 dB @ 1 kHz @ 1% THD, 1 kΩ load
- Signal to Noise Ratio 70.5 dB referenced @ 94 dB SPL @ 1 kHz (S/N ratio is difference between 94 dB SPL and equivalent SPL of self noise, A-weighted)
- Dynamic Range 117 dB @ 1 kHz @ 1 kΩ load
- Clipping Level -6 dBV (0.5 V), @ 1 kHz @ 0.25% THD, 1 kΩ load
- Self Noise 22 dB (typical, equivalent SPL; A-weighted)
- Mic Offset Range 0 to 21 dB (in 3 dB Steps)
- Frequency Band V50: 174 to 216 MHz
- Audio Input Configuration: Unbalanced
- Maximum Input Level 1 kHz @ 1% THD
- RF Output Antenna Type: Integrated Single-Band Helical
- Occupied Bandwidth: < 200 kHz
- Modulation Type: Shure Proprietary Digital
- Power: 1 mW, 10 mW, 20 mW (Varies by Region)
- Battery Type 2x LR6 AA Batteries 1.5 V
- Shure SB900 Rechargeable Li-Ion
- Battery Life Shure SB900: > 11 Hours @ 10 mW
- Alkaline Batteries: > 11 Hours @ 10 mW
- Housing Machined Aluminum
- Dimensions (Ø x L) 2 x 10.1" (51 x 256 mm)
- Weight 12 oz (340 g)
