SPECIFICATIONS IN DETAIL
We always quote 'real world' performance figures (measured to the AES17 standard). Some companies choose to quote chipset performance, which is misleading
SUPPORTED SAMPLE RATES
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
MICROPHONE INPUTS
- Frequency Response
- 20Hz - 20kHz ± 0.1dB
- Dynamic Range
- 111dB (A-weighted)
- THD+N
- <0.0012%
- Noise EIN
- -128dBu (A-weighted)
- Maximum Input Level
- 9dBu (at minimum gain)
- Gain Range
- 56dB
- Impedance
- 3kΩ
LINE INPUTS
- Frequency Response
- 20Hz - 20kHz ± 0.1dB
- Dynamic Range
- 110.5dB (A-weighted)
- THD+N
- <0.002%
- Maximum Input Level
- 22dBu (at minimum gain)
- Gain Range
- 56dB
- Impedance
- 60kΩ
INSTRUMENT INPUTS
- Frequency Response
- 20Hz - 20kHz ± 0.1dB
- Dynamic Range
- 110dB (A-weighted)
- THD+N
- <0.03%
- Maximum Input Level
- 12.5dBu (at minimum gain)
- Gain Range
- 56dB
- Impedance
- 1.5MΩ
LINE/MONITOR OUTPUTS
- Dynamic Range (Line Outputs)
- 108dB
- THD+N
- <0.002%
- Maximum Output Level (0 dBFS)
- 15.5dBu
- Impedance
- 430Ω
HEADPHONE OUTPUTS
- Dynamic Range
- 104dB (A-weighted)
- THD+N
- <0.002%
- Maximum Output Level
- 7dBu
- Impedance
- <1Ω
