Description
Dynamic Light Shows—No Operator Needed
Dynamic lighting elevates the energy and excitement of any interactive event, from music concerts and dance clubs to house parties and the local karaoke bar. With the VC-1-DMX Video Lighting Converter, it’s never been easier to bring the impact of a pro light show to any event you put on.
The VC-1-DMX automatically generates control commands for your DMX lighting setup based on input from video and audio sources, eliminating the need for a dedicated lighting operator. Color and brightness change based on the current video image, and lights and mirror balls operate in sync with the music tempo. And if you want to dive deeper, the VC-1-DMX supports external MIDI operation from hardware control surfaces, electronic musical instruments, and computer-based production software.
- Automatically generates dynamic lighting effects to enhance any event
- Outputs a DMX signal synchronized with incoming video and audio signals
- Real-time analysis and lightning-fast processing with advanced Roland technology
- Connect your A/V source to the HDMI input for analysis and distribute the unprocessed signal to a monitor or switcher via HDMI thru
- Analog audio also supported with stereo I/O
- Supports external MIDI control via dedicated MIDI input and USB MIDI
- Customize DMX settings with dedicated software for macOS and Windows
- Remotely choose maps with the default settings of the BOSS FS-1-WL MIDI footswitch (a TRS to 5-pin MIDI cable such as the BOSS BMIDI-5-35 is required for connection)
True Synchronized Lighting Made Easy
Connect video, audio, and MIDI sources to the VC-1-DMX for automatic conversion and distribution to all your DMX gear. It’s even possible to daisy-chain multiple lighting devices and control them at once. Four channel maps are available via dip switches to control 512 DMX signal channels, and you can customize them all from a computer using the VC-1-DMX Setup Tool.
Advanced Video Analysis
HDMI video signals* are analyzed in up to 32 color areas and converted into luminance information for each color. You can then assign the colors to DMX channels for synchronized control. For example, if the video image is divided horizontally into eight segments and assigned to eight DMX lighting devices lined up horizontally, the lighting will track the horizontal movement of the video image perfectly.*HDCP compliant.
Lighting That Moves with the Music
The VC-1-DMX also analyzes sound information received at the HDMI and analog audio inputs. Add flash effects along with the beat, change the rotation speed of a mirror ball or other device to match the music tempo, or automatically turn off the lights when there is no sound. A powerful 15-band audio filter added with Version 2.0 allows you to set lighting controls to specific audio frequency ranges for deep synchronization between the lights and music. Using the VC-1-DMX Setup Tool, you can define the bandwidth and gain level of each band for precise command of your DMX rig.Go Further with MIDI Control
If you want extended control over your system, the VC-1-DMX has you covered with integrated MIDI-to-DMX conversion. Connect a hardware MIDI controller and use MIDI control change messages to switch DMX maps* and adjust DMX parameters such as global dimming, tilt, pan, and more. Or use MIDI note information from keyboards, electronic drums, and other instruments to create lighting effects that follow live music performances. USB MIDI is also supported, allowing you to control your DMX setup from lighting or music production software on your computer.
*The default MIDI control change settings of the BOSS FS-1-WL provide direct support for VC-1-DMX map selection (wired MIDI cable connection required).
Customize Your Rig
Using the VC-1-DMX Setup Tool software for macOS and Windows, you can quickly configure the VC-1-DMX for all your DMX lighting hardware. Freely change assignments across 512 DMX channels to match the control needs of your specific gear and easily share settings with multiple VC-1-DMX units.
APPLICATIONS
Party Spaces
Energize the environment in bars, nightclubs, banquet halls, and other party spaces with lighting that’s automatically synchronized to any video source.
Business Events and Presentations
Create more impact at business events with dynamic lighting that follows slides and video content from presentation software.
Band and DJ Performances
During live music performances, drive the VC-1-DMX and the house lighting system from MIDI-equipped gear like keyboards, electronic drums, and DJ controllers.
Karaoke
Give karaoke singers and audience members the feel of a concert performance with dynamic lighting that matches the music.
VIDEOInput ConnectorHDMI IN connector : HDMI type A
* HDCP Supported
* Multi-format SupportedOutput ConnectorHDMI THRU connector : HDMI type AVideo Formats480/59.94i, 576/50i, 480/59.94p, 576/50p, 720/59.94p,
720/50p, 1080/59.94i, 1080/50i, 1080/59.94p, 1080/50p,
VGA (640 x 480/60 Hz), SVGA (800 x 600/60 Hz), XGA (1024 x 768/60 Hz),
HD (1280 x 720/60 Hz), WXGA (1280 x 800/60 Hz), SXGA (1280 x 1024/60 Hz),
FWXGA (1366 x 768/ 60 Hz), SXGA+ (1400 x 1050/60 Hz),
UXGA (1600 x 1200/60 Hz), FHD (1920 x 1080/60 Hz)
* The refresh rate is the maximum value of each resolution.
* Conforms to CEA-861-E, VESA DMT Version 1.0 Revision 11.AUDIOInput ConnectorsAUDIO IN jacks : RCA phono type
HDMI IN connector : HDMI type AOutput ConnectorsAUDIO OUT jacks : RCA phono type
HDMI THRU connector : HDMI type ADigital Audio FormatLinear PCM, 48 kHz, 24 bits, stereoAudio ProcessingSample rate : 48 kHz, 24 bitsNominal Input LevelAUDIO IN jacks : -10 dBu (Maximum input level : +8 dBu)Nominal Output LevelAUDIO OUT jacks : -10 dBu (Maximum input level : +8 dBu)Input ImpedanceAUDIO IN jacks : 15 k ohmsOutput ImpedanceAUDIO OUT jacks : 1 k ohmsDMXOutput ConnectorsDMX OUT 3 pin jack : XLR type (3 pins)
DMX OUT 5 pin jack : XLR type (5 pins)DMX channel512 channels (1 universe)OTHERSControl TerminalMIDI IN jack
USB portSwitchesSETTING switch : 8 terminalsIndicatorPOWER indicatorFunctionsVideo Synchronized Lighting Control
Audio Synchronized Lighting Control
MIDI Synchronized Lighting Control
Lighting Speed Control
HDMI Audio De-embedderPower SupplyAC AdaptorCurrent Draw1,000 mACurrent Consumption5.7 WOperation Temperature+0 to +40 degrees Celsius
+32 to +104 degrees FahrenheitDimensions180 (W) x 115 (D) x 41 (H) mm
7-1/8 (W) x 4-9/16 (D) x 1-5/8 (H) inchesWeight (excluding AC adaptor)570 g
1 lb 5 ozAccessoriesLeaflet "USING THE UNIT SAFELY"
Owner's Manual
AC Adaptor
Plug Holder
Rubber Feet
