RODELink represents the next generation of digital wireless systems. Using a Series II 2.4GHz digital transmission with 128-bit encryption, it is able to constantly monitor and hop between frequencies to maintain the strongest possible signal level at a range of up to 100 metres* (over 100 yards). The RODELink Filmmaker Kit provides everything you need to start shooting video wirelessly, including a receiver, transmitter and broadcast-grade lavalier microphone. The receiver (RX-CAM) features an OLED display with information on level, battery status (receiver and transmitter), mute and channel selection. The unit can be mounted on a standard camera shoe mount, 3/8" thread or belt-clip, and for added versatility the shoe mount can be located in one of two positions. The lightweight transmitter (TX-BELT) can be fitted to a belt or clothing and features a locking thread to ensure the microphone connection is as secure as possible. RODE has included an omnidirectional lavalier microphone in the kit to provide the highest possible audio reproduction quality.
* range estimations based on optimal environment
RODELink Filmmaker Kit Specifications
Series II, 2.4GHz digital transmission
128-bit encryption
Up to 100 metres range*
OLED display (on receiver)
One button pairing
Three level gain control
AA battery or USB powered
Includes broadcast lavalier microphone
Transmission type
2.4GHz Fixed Frequency Agile System
System dynamic range
112dB
Range (distance)
Up To 100m
Frequency range
35Hz - 22kHz
Maximum output level
1v Rms (2.8v P-p)
Max input signal level
1v Rms (2.8v P-p)
Max latency
4ms
Receiver (RX-CAM)
Power source
2 X AA Battery Or MicroUSB
Antenna
Internal
Output connection
3.5mm TRS Locking Jack Socket - Dual Mono
Output impedance
300 Ohm
Dimensions
111mm X 65mm X 52mm
Weight
190gm
Transmitter (TX-BELT)
Power source
2 X AA Battery Or MicroUSB
Antenna
Internal
Input connection
3.5mm TRS Locking Jack Socket
Input impedance
10khz
Dimensions
111mm X 65mm X 40mm
Weight
190gm
R√òDELink LAV
ACOUSTIC ELECTRICAL SPECIFICATION
Acoustic Principle
Permanently Polarised Condenser
Polar Pattern
Omni-directional
Output Impedance
3k kHz Typical
Frequency Range
20Hz - 20kHz
Maximum SPL
110 dB SPL (@ 1kHz, 1% THD into 1Å’e load)
Sensitivity
-33.5db re 1 Volt/Pascal (21.00mV @ 94 dB SPL) +/- 2dB @ 1kHz
Signal to noise Ratio
67 dB
Equivalent Noise (A-weighted)
27 dB Typical
Dynamic Range
83 dB Typical
