Name: RANE SEVENTY A-TRAK - Signature Edition - 2 channels battle mixer
Brand: RANE
SKU: ATRAK-SEVENTY
Availability: OutOfStock

RANE SEVENTY A-TRAK - Signature Edition - 2 channels battle mixer

Roll over image to zoom in Click on image to zoom

Pushing the Boundaries of

Turntablist Performance

Sonic innovation in a battle-tested frame

Stunning Custom Design

The exterior of the SEVENTY A-TRAK SIGNATURE EDITION features a stunning silver finish than gleams beneath the aluminum-capped rotary-styled knobs and encoders.

Enhanced Capabilities

Fader FX transforms the channel volume faders into linear controllers for performance effects like Filter, Roll, Pitch, Ring Modulator, and four types of Oscillators.

Sonic Innovation

The sound curve and frequency response of the mixer was handcrafted by A-Trak himself, increasing the depth of the low end to ensure that the high-quality audio matches his signature sound.

Digital Audio
Converters	AKM High Definition Audio; 24-bit PCM, 48 kHz
Digital Signal Processing	32-bit, floating point, double precision
Dynamic Range (A-weighted, unity gain)	ADC DAC CD Input to Analog Output CD Input to USB Output USB Input to Analog Output	114 dB 114 dB 114 dB 114 dB 114 dB
Inputs
Microphone 1/2 (Combo XLR/1/4" [6.35 mm] TRS, Mic/Line switchable)	Analog Gain Maximum Input Gain Trim	30 dB (Mic), 4.75 dB (Line) 0.126 Vrms (Mic), 2.3 Vrms (Line) Off to +20 dB (unity at center)
Aux Inputs 1/2 (RCA stereo pairs)	Maximum Input Dynamic Range (A-weighted)	4 Vrms 114 dB
CD/Phono Inputs 1/2 (RCA stereo pairs, switchable)	CD Maximum Input Dynamic Range (A-weighted) Phono RIAA Curve Gain (@ 1 kHz) Maximum Input (@ 1 kHz)	Line 4 Vrms 114 dB RIAA +0.1/-0.2 dB 30 dB 126 mV
Session Input (RCA stereo pair)	Maximum Input Dynamic Range (A-weighted)	4 Vrms 114 dB
Outputs
Main Outputs (XLR)	Frequency Response Maximum Output THD+N (@ 1 kHz, 4 Vrms)	20 Hz to 20 kHz (± 0.2 dB) 8 Vrms 0.002%
Booth Outputs (1/4"/6.35 mm TRS)	Frequency Response Maximum Output THD+N (@ 1 kHz, 4 Vrms)	20 Hz to 20 kHz (± 0.2 dB) 8 Vrms 0.002%
Session Outputs (RCA stereo pair)	Frequency Response Maximum Output THD+N (@ 1 kHz, 2 Vrms)	20 Hz to 20 kHz (± 0.2 dB) 4 Vrms 0.002%
Headphone Outputs (1/4"/6.35 mm and 1/8"/3.5 mm TRS)	Maximum Output Voltage THD+N (@ 1 kHz, 2 Vrms) Output Power Controls	4 V (no load) 0.003% 96 mW (50 ohms) On/Off muting
General
Display	1.6” OLED (diagonal)
Pads	(16) velocity-sensitive multi-color back-lit pads (8 per deck, 10 modes each)
Faders	(3) MAG FOUR tension-adjustable faders (2 channel/line faders, 1 crossfader)
Connectors	(2) XLR outputs (Main) (2) 1/4” (6.35 mm) TRS outputs (Booth) (4) RCA stereo input pairs (Deck 1–2) (2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1–2) (1) RCA stereo input pair (Session) (1) RCA stereo output pair (Session) (1) 1/4” (6.35 mm) TRS output (Headphones) (1) 1/8” (3.5 mm) TRS output (Headphones) (2) USB Type-A ports (Deck 1–2 USB Controllers) (2) USB Type-B ports (1) IEC power cable input
Power	Connection: IEC Voltage: 100–240 V, 50/60 Hz Consumption: 30 W
