Air and transient response.
Driven by a dedicated 65 watt Class A/B amp, the R65 V2’s custom-designed 6.8-square-inch Air Motion Transformer (AMT) excels at accurate reproduction of the highest of high frequencies—those responsible for a sense of air, space, and dimensionality. And the AMT’s astonishingly thin (< 0.01 mm) folded Kapton® membrane allows the tweeter to move in the same instant as the voltage cycles that power it, providing nothing less than wave cycle-accurate transient reproduction.
Wide with pride.
The unique AMT design also allows the R65 V2 to handle 8 to 13 times the projection area of more traditional tweeter designs, while the R65 V2’s unique housing constrains this projection area to the horizontal axis. The result is a very wide sweet spot with focused vertical dispersion, —minimizing reflections off of your desk, ceiling, and floor that could otherwise introduce problematic phase and coherence issues. And because it’s less subject to room-anomaly interference, the R65 V2 studio monitor reacts predictably and sounds consistent, even if moved to different listening environments.
The lowdown on the down-low.
R65 V2’s woofer is six and a half inches of rigid, custom-woven composite that offers consistent dispersion across its frequency range for the flattest response we could design. A dedicated 75 watt Class A/B amplifier provides ample headroom and impressive distortion-free, non-fatiguing performance—even at higher volumes.
The new versatility.
Improving the respected R-series classics wasn’t easy, but we found a way: by giving you more control than was available on the original R65. The updated R65 V2 features analog acoustic tuning controls that will be familiar to users of our celebrated Eris® line—you get Low Cut, Mid Frequency, and High Frequency controls, as well as a three-way Acoustic Space switch that allow you to easily compensate for the sonic consequences of speaker placement against a wall or in a corner. We also added a new Class A/B amplifier to provide an even warmer and smoother overall frequency response.
Studio monitor connections.
Of course, you also get classic PreSonus monitor connectivity, as R65 V2 provides balanced XLR, balanced ¼-inch TRS, and unbalanced RCA line-level inputs, so you can hook them up to an audio interface, mixer, monitor controller, or almost any other line-level source. If you’d like to add Bluetooth connectivity, check out the microstation bt
Accuracy defined.
The R65 V2 studio monitor provides lifelike audio reproduction that will allow you to hear the room in your recordings. Its transparent sound and responsive transient reproduction makes it an ideal solution for anyone who is mixing high-resolution audio. The exact same AMT technology that provides the R65 V2’s natural-sounding, honest playback also ensures that potential trouble spots in your mixes won’t slip past your critical ear.
Features
- 2-way active AMT tweeter design provides articulate high-frequency response, wide stereo imaging, and narrow vertical dispersion
- Custom-designed, 6.8-inch, AMT tweeter responds to the subtlest waveforms and the highest frequencies for audiophile-grade air and space
- 6.5-inch LF drivers provide transparent mid- and low-frequency reproduction for clean, punchy bass
- Biamped, 140 W RMS (LF = 75 W, HF = 65 W) Class A/B power amplifier with switching power supply
- Acoustic tuning controls (Low cut, Mid, High, Acoustic Space) compensate for room acoustics and placement
- Studio One Prime and Studio Magic Software Suite ($1,000 value!)
- Balanced XLR and ¼-inch TRS plus unbalanced RCA inputs provide flexibility for seamless integration into any environment
- Toroidal power transformer eliminates noise and hum
- System protections include RF interference, output current limiting, over-temperature, turn-on/off transient, subsonic filter, external mains fuse
- Power: 100-120 V ~50/60 Hz or 220-240 V ~50/60 Hz
| |
R65 V2 |
R80 V2 |
Inputs |
||
| 1- Balanced XLR | 1- Balanced XLR | |
| 1- Balanced ¼” TRS | 1- Balanced ¼” TRS | |
| 1- Unbalanced RCA | 1- Unbalanced RCA | |
Performance |
||
| Frequency Response | 45 Hz – 22 kHz | 40 Hz – 22 kHz |
| Crossover Frequency | 2.7 kHz | 2.6 kHz |
| LF Amplifier Power | 75W Class AB | 75W Class AB |
| HF Amplifier Power | 65W Class AB | 65W Class AB |
| Peak SPL (@ 1 meter) | 104 dB | 107 dB |
| LF Driver | 6.5” woven composite | 8” woven composite |
| HF Driver Type | AMT | AMT |
| Diaphragm | 6.8-inch2 (4,400 mm2) | 6.8-inch2 (4,400 mm2) |
| Equiv. Diaphragm ø | 3” (75 mm) | 3” (75 mm) |
| Input Impedance | 20 kΩ balanced, 10 kΩ unbalanced | 20 kΩ balanced, 10 kΩ unbalanced |
| SNR (typical, A-weighted) | >100 dB | >100 dB |
User Controls |
||
| Volume Range | A-type taper | A-type taper |
| High-frequency Control |
+/- 6dB shelf @ 10kHz |
+/- 6dB shelf @ 10kHz |
|
Mid-frequency Control |
+/- 6dB @ 1kHz |
+/- 6dB @ 1kHz |
| Low Cut |
Flat, 80Hz, or 100Hz |
Flat, 80Hz, or 100Hz |
|
Acoustic Space |
Flat, -2dB or -4dB |
Flat, -2dB or -4dB |
Protection |
||
| RF interference | RF interference | |
| Output-current limiting | Output-current limiting | |
| Over-temperature | Over-temperature | |
| Turn-on/off transient | Turn-on/off transient | |
| Subsonic filter | Subsonic filter | |
| External mains fuse | External mains fuse | |
Power |
||
| Factory preprogrammed | 100-120V ～50/60 Hz or 220-240V ～50/60 Hz | 100-120V ～50/60 Hz or 220-240V ～50/60 Hz |
| Standby Power | < 0.5W | < 0.5W |
Cabinet |
||
| Vinyl-laminated, medium-density fiberboard | Vinyl-laminated, medium-density fiberboard | |
Physical |
||
| Width | 8” (203 mm) | 9.5” (241 mm) |
| Depth | 10.3” (261 mm) | 12” (309 mm) |
| Height | 13” (328 mm) | 15” (379 mm) |
| Weight | 14.7 lbs (6.65 kg) | 19.8 lbs (9 kg) |
