Overview
No need to bring separate stands for stage lighting and speakers when NX10C-2's can be mounted under the light bars, saving valuable stage space.
For side-wash monitor applications on tight stages, the NX10C-2 can be mounted under the front of house cabinets to provide a monitor signal that will be fully phase coherent with the front of house signal.
The innovative custom rear mounted handle also functions as a tilt stand allowing the NX10C-2 to be used as a compact wide coverage floor monitor or center fill cabinet.
Versatile inputs for mic or line level sources as well as an 1/8th-inch TRS jack allow the NX10C-2 to direct connect to any audio source.
Features
- No need to bring separate stands for stage lighting and speakers when NX10C-2's can be mounted under the light bars, saving valuable stage space.
- For side-wash monitor applications on tight stages, the NX10C-2 can be mounted under the front of house cabinets to provide a monitor signal that will be fully phase coherent with the front of house signal.
- The innovative custom rear mounted handle also functions as a tilt stand allowing the NX10C-2 to be used as a compact wide coverage floor monitor or center fill cabinet.
- Versatile inputs for mic or line level sources as well as an 1/8th-inch TRS jack allow the NX10C-2 to direct connect to any audio source.
- Made in Canada
Specifications
| Active or Passive |
Active |
| Power Rating (Watts) |
500 Watts (1200 Watts Peak) |
| Biampable |
Self Powered |
| Max SPL (dB) |
127dB Peak (124dB Continuous) |
| Frequency Response (Hz +/- 3dB) |
80Hz - 20kHz |
| Crossover Frequency (Hz) |
2500Hz |
| Driver Configuration |
Coaxial 10-inch/1-inch |
| HF Driver(s) |
1-inch Throat, Ceramic Magnet, 1.4 inch PETP Film |
| HF Dispersion (°H x °V) |
60 x 60 |
| LF Driver(s) |
10-inch Ceramic Magnet with a 2.5" voice coil |
| HF Amplifier Type |
Class A/B |
| LF Amplifier Type |
3 Tier Class- H |
| Power Cable |
Yes |
| Power Switch |
Yes |
| Power Consumption (typ/max) |
120 / 310 VA |
| Inputs |
3 (Combi-jack Mic Input / Combi-jack Line Input / 1/8-inch TRS Line Input) 1/4" inputs are parallel |
| Input Sensitivity (Vrms Sine) |
1.23 Vrms, +4dBu |
| Mixer Controls |
EQ (Playback/Bright) |
| Level Controls |
Line/Mic |
| Limiter |
Yes |
| LED Indicators |
Power, Clip |
| Feet |
Yes |
| Pole Mount Adapter (1 3/8"-3.5cm) |
Pole Through |
| Enclosure Materials |
Injection Molded Fiber Reinforced ABS / Aluminum/13ply birch |
| Grille |
Perforated Steel |
| Dimensions (DWH xbackW, inches) |
13 X 13.5 X 12 |
| Dimensions (DWH xbackW, cm) |
33 x 34.3 x 30.5 |
| Weight (lbs/kg) |
25 / 11.3 |
Specifications subject to change without notice
