Ideal for shopping malls, sports bars, and health clubs
Vented LF enclosure
1-inch titanium diaphragm HF driver with neodymium magnetic structure
Coherent Coverage Waveguide
Full-bandwidth overload protection (LF and HF)
Elliptical weather-resistant ABS enclosure
Paintable black or white finish
Magnetically shielded for video applications
Strong-Arm Mount for easy, flexible aiming
"T" version for 70 or 100 V distributed systems
SPECIFICATIONS
Frequency Response ¹ ( z -10 dB)
62 Hz - 20 kHz
Power Handling ²
300W Cont. Prog./600W Peak
Sensitivity ³
94 dB, 1W/1m
Impedance
8 ohms
Max SPL
118 d
Horizontal Coverage⁴
100°
Vertical Coverage⁴
80°
Crossover Frequency
1.6 kHz
LF Transducer
2 x 6" (100 mm)
HF Transducer
1" (25 mm)
Protection
Full Syste
Weather Resistance
Meets Mil Spec 810 humidity, salt spray, temperature and UV, and IEC 529 IP 34 splashproof ratings
Swing x Rotation
100° x 90°
Terminals
Phoenix Connector
Enclosure Material
ABS (paintable)
"t" Version Wattage Taps
70V 7.5 W 70V/100V 15W, 30W, 60W, 8 ohm bypass
Dim (H x W x D)
16.5" x 9" x 11.75" (419 mm x 228 mm x 298 mm)
Net Weight (each)
12 lbs (5.3kg)
Shipping Weight (pair)
27 lbs (12.3 kg)
Included Accessories
SAM™, hex key
¹ Half Space (wall mounting) ² Continouous Program Rating: 3 dB greater than continuous pink noise rating (IEC-shaped pink noise with 6dB crest factor) ³ Avg: Half Space (wall mounting) ⁴ When mounted with long axis in vertical plane
