Description
Standalone – no computer required | 8x8 clip launch matrix with RGB LEDs | 7-inch full color capacitive multitouch display | Mic/instrument/line inputs, 4 outputs | MIDI In/Out/Thru | 4 configurable CV/Gate outputs | Disk Streaming | Remix, mash-up, DJ and produce with 6 track types for complete audio/MIDI/CV sequencing and performance capability | Performance Modes including 16-Pad Drums, Notes, Smart Scales, Chords & Progressions | Class-compliant USB Interface Support | MPC Sample Editing | Automatic BPM detection, real-time time-stretching and pitch-shifting | 8 touch-sensitive knobs with graphical OLED displays | 4 powerful, fully-editable synth engines | 16GB of on-board storage (over 10GB of sound content included) | Full-Size SD card slot & 2 USB 3.0 slots for thumb drives or MIDI controllers | User-expandable 2.5-inch SATA drive connector (SSD or HDD)
Ability to run all the latest Plugins and EFFects
MPC Sequences
Stem Separation*
Follow Actions
Tempo Automation
Advanced Key Groups with Synth Engines
Drum Track and Keygroup Modifiers
Warp Algorithm Choice
New Record Launch Mode: Record to SelectioN
Run loads of studio-grade plugins and effects—like Sub Factory, Lo-Fly Dirt, Delay Pro, and MPC Stems—with the new 3.5 firmware update.*
Export Drum Pads as Separate Stems
Faster Sample Loading
Sliced to Audio Track
Track View
New Main Mode
Arrange Tab
Main Mode - XL Channel Strip
Sounds Mode
Track Edit Improvements
Key Features
On-Board Storage
Full-size SD card slot
USB-A 3.0 slots for thumb drives
Wirelessly connect your Bluetooth® compatible device
Play in time with Ableton Link
CV Outputs
8x8 Clip Launch/Performance Pad Matrix
Disk Streaming
Key Specs
Pads
- (64) velocity- and pressure-sensitive pads, RGB-backlit
Knobs
- (8) 360° touch-sensitive Knobs
- (1) 360° encoder for display navigation and selection via push
- (5) 270° knobs for gain, mix & level adjustment
Buttons
- (56) dedicated function buttons; red-, amber-, or green-backlit
Display
- 6.9” / 176 mm (diagonal)
- 5.9” x 3.7” / 150 x 93 mm (width x height)
- Full-color LED-backlit display with touch interface
Connections
- (2) XLR+1/4” (6.35 mm) TRS inputs (Input 1/2)
- (4) 1/4” (6.35 mm) TRS outputs (2 stereo pairs)
- (1) 1/4” (6.35 mm) stereo headphone output
- (1) 1/8" (3.5 mm) MIDI input
- (1) 1/8" (3.5 mm) MIDI output
- (1) 1/8" (3.5 mm) MIDI thru port
- (4) 1/8” (3.5 mm) CV/Gate outputs
- (1) Ethernet link port
- (2) USB Type-A ports
- (1) USB Type-B port
- (1) SD card slot
- (1) power adapter input
Power
- via power adapter: 19 V, 3.42 A, center-positive, included
Dimensions (width x depth x height)
- 13.8” x 15.3” x 2.85”
- 350 x 389 x 72.5 mm
Weight
- 8.53 lbs.
- 3.87 kg
