| Coverage (H x V) |
90° x 60° |
| Power Rating |
2000 W |
| LF Transducer |
SMX2120 300 mm (12 in) |
| HF Transducer |
DH3-B 1.25-in titanium compression driver |
| Crossover Frequency |
1600 Hz |
| Connectors |
(2) XLR/TRS combo jack and (1) XLR link output |
| Enclosure |
18mm Plywood with EVCoat |
| Grille |
16AWG steel with powdercoat |
| Suspension |
(8) M10 suspension points |
| Dimensions (H x W x D) |
613 mm x 381 mm x 400 mm (24 in x 15 in x 16 in) |
| Net Weight |
23.6 kg (52.0 lb) |
| Shipping Weight |
26.8 kg (59.1 lb) |
| Power Consumption |
100 - 240 V~, 50 - 60 Hz, 1.6 - 0.8 A³ |
