The Chauvet Pro Rogue Outcast 1 BeamWash is poised to become your new favorite fixture! Replete with wide zoom angles, tight beam capabilities, and sensational color mixing, this fixture packs a top-notch visual punch for any stage. Rated IP65, the Rogue Outcast 1 can withstand the temporary battering of outdoor weather, while a weight of 20 pounds makes installation and teardown easy. The Rogue Outcast 1 features seven 45W RGBW eye-catching LEDs and a pixel-mappable LED ring equipped with pre-built programs that lighting mavens have found to create cosmic shows and entrancing productions. Control modes range from simple to advanced providing you with a range of DMX and RDM intricacy to suit the needs of your busy schedule!
Captivating LED ring pixel-mapping capabilities
What really sets the Rogue Outcast 1 apart from its peers lies in the LEDs under the hood. A pixel-mappable LED ring offers 12 zones of RGB control, making for enthralling effects. When not needed, the ring disappears under its smoked stealth filter, effectively concealing it so the seven LEDs in the face can shine unfettered or the fixture can vanish into the darkness of the stage. Pre-built programs entail control over dimming, rate, and foreground and background colors. Plus, 16-bit dimming complete with six dimming modes puts the power in your hands to captivate your audience.
Tight and smooth beam and wash functions
Apart from the mesmerizing effects of the LED pixel-mappable ring, the Rogue Outcast 1 also offers a wide range of beam and wash capabilities. A zoom range of 3.9° to 55.3° ensures you’ll be able to set the beam angle to the perfect specifications needed for a song, performance, or event. Incredibly fast and smooth pan and tilt movement, as well as selectable PWM for cameras, tops off this fixture with an astounding range of stellar features.
Features
-
x 45W RGBW LEDs in the face create captivating beam and wash effects
- Outer RGB LED ring offers 12 pixel-mappable zones
- Engaging pre-built programs for control over dimming, rate, foreground, and background colors
- Smoked stealth filter lets ring vanish when not in use
- Wide zoom range of 3.9°–55.3° for tight beams and wide washes
- Rated IP65 for temporary outdoor use
- 16-bit dimming with 6 dimming modes
- Fast, smooth pan and tilt
- Selectable PWM for use with cameras
- Unique lens design offers tight beam effects
- Lightweight 20 lb. design makes installation and tear-down easy
- Simple and advanced control modes for DMX and RDM
- Color mixing with punchy output
- USB-C port for easy software updates
- 5-pin DMX input/output connections
- OLED menu display for easy navigation
Specifications
- Type: Moving Head Beam/Wash
- DMX: 5-pin In/Out
- DMX Modes: 15, 24, 30, 64, 111, 135 channels
- LED: 7 x 45W LED
- LED Type: RGBW
- Illuminance: 15,308 lux @ 5m (3.9°), 473 lux @ 5m (55.3°)
- Beam Angle: 3.9°-36°
- Pan & Tilt: Pan - 540°/360°/180° ; Tilt - 260°/180°/90°
- Power Consumption: 385W 3.25A @ 120V
- Power Supply: Seetronic Powerkon IP65 (cable included)
- Height: 15.75"
- Width: 11.92"
- Depth: 7.58"
- Weight: 20.2 lbs.
-
IP65 rated, LED Beam & Wash, Light Source: 7 LEDs (quad-color RGBW) 45W, (3 A), 50,000 hours life expectancy Light Source: 97 LEDs Outer Ring (tri-color RGB) 0.2 W,(20 mA), 50,000 hours life expectancy Color Temperature (range): 2800 to 10000 K Pan and Tilt: 540°/260° Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 260° tilt Dimmer: Electronic Shutter/Strobe: Electronic Zoom: Motorized Strobe Rate: 0 to 20 Hz Standalone Color Mixing: Yes Control Protocol: DMX, RDM DMX Channels: 15, 24, 30, 64, 111 or 135 Modes/Personalities: 6 personalities (15, 24, 30, 64, 111,135) Power Connection: Edison plug to Seetronic Powerkon IP65 Data Connectors: 5-pin XLR
