Maverick Force 3 Profile brings quick movement and fast effects together in a blazingly bright LED yoke profile fixture that harnesses the latest technology to deliver 40,906 lumens of output. Precision optics capture the depth of a CMY + CTO color mixing system renowned for its real reds and maintain a flat field of focus even when taking its 10:1 zoom fully wide. Color calibration and gobo selection comes matched to other Force fixtures in the rig, along with the advanced 4-blade shutter frame system and effects wheelhouse that delivers the great static, rotating, and animation effects the Force series is known for. Take control with DMX, RDM, sACN, Art-Net, or W-DMX.
-
Full featured 915 W LED yoke profile fixture including CMY+CTO color mixing, a four blade framing shutter system with rotation, a color wheel, a CRI filter, animation wheel, a 10:1 zoom, two independently layerable prisms, two frosts, a static and a rotating gobo wheel
-
16-bit dimming of master dimmer for smooth control of fades
-
Variable CMY + CTO color mixing system to create a wide pallet of colors
-
CRI and CTB filters on color wheel for added flexibility
-
Independently layerable five facet linear and five facet round prisms for increased prism options
-
One rotating and one static gobo wheel for dynamic texture possibilities
-
Independent light and medium frosts for beam control
-
+ or – 60 degree rotation framing shutter system to allow for better framing positioning.
-
Animation wheel for enhanced visual effects
-
Iris for total beam control
-
DMX, WDMX, sACN, and Art-Net for full flexibility of control options
-
RDM control over DMX for fixture reporting
-
4.9° to 53.9° zoom angle for variable beam sizes
-
Three menu presets and preset cross load for decreased shop setup time
-
True 1 compatible power input
-
USB slot for software uploads
-
Battery backup display with auto-rotate depending on fixture orientation.
-
Failsafe Ethernet connectivity allows for data to pass even if fixture power is lost.
OPTICAL
- Light Source: 1 LEDs (CW) 915 W, (4.3 A), 7500 K, 50,000 hours life expectancy
- Color Temperature (at full): 7228 K
- CRI: 70.9
- CRI with CRI Filter: 89.4
- Front Lens Diameter: 160 mm
- Beam Angle: 4.9 ° to 42.8°
- Field Angle: 5.8° to 49.4°
- Cutoff Angle 6.5° to 53.6°
- Zoom Range: 4.9° to 53.9°
- Lumens – Source: 62,000
- Lumens – Output: 40,906
- Illuminance (4.9°) 130,582 lux @ 5 m
- Illuminance (53.9°) 3,792 lux @ 5 m
- Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
DYNAMIC EFFECTS
- Pan and Tilt: 540°/270°
- Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
- Colors: 6 (including CRI and CTB filters) + white, split colors, continuous scroll at variable speeds
- Colors: CMY flags
- Gobos (1): 7 + open glass, rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
- Gobos (2): 9 + open glass, static, continuous scroll at variable speeds
- Gobo Size: Gobo Wheel 1 (rotating): 27 mm (outside), 22 mm (image), 1.1 mm (max. thickness)
- Gobo Size: Gobo Wheel 2 (static): 27 mm (outside), 22 mm (image), 1.1 mm (max. thickness)
- Framing Shutters: 4 blades, each with dual axis movement.
- Framing Shutter rotation: +/- 60° rotation.
- Dimmer: Electronic
- Shutter/Strobe: Electronic
- Zoom: Motorized
- Focus: Motorized
- Frost: Motorized
- Iris: Motorized
- Prism: 5 Linear Facets, motorized, rotating
- Prism: 5 Circular Facets, motorized, rotating
- Strobe Rate: 0 to 26 Hz
- Move-in-Black: Yes
- Dim Curves: 4
CONSTRUCTION / PHYSICAL
- Dimensions: 16.73 x 10.98 x 30.47 in (425 x 279 x 774 mm)
- Weight: 84.2 lb (38.2 kg)
- Exterior Color: Black
- Housing Material: High-impact flame-retardant polymer
