CHAUVET PRO EPIX-FLEX-BOOST - doubles the capacity of each output on the EPIX-FLEX DRIVE and the quantity of EPIX-FLEX 20 it controls.

ÉPIX Flex Boost is a 24V in-line voltage booster that doubles the capacity of each output on the EPIX-FLEX DRIVE and the quantity of EPIX-FLEX 20 it controls. There is no need to solder into system with this plug-and-play operation.

• IP65 outdoor rated in-line voltage booster for ÉPIX Flex 20

• Works when connected to the outputs of the ÉPIX Flex Driver

• CONSTRUCTION / PHYSICAL

  • Dimensions: 8.13 x 3.56 x 1.83 in (206.5 x 46.5 x 90.5 mm)
  • Weight: 4.4 lb (2 kg)
  • Exterior Color: Black
  • Housing Material: Aluminum


  CONNECTIONS

  • Connection: Edison (Local) plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Device inputs: (1) 3-pin male IP Flex
  • Device Outputs: (1) 3-pin female IP Flex
  • Physical Linking: 2 inline ÉPIX Flex 20
  • Cable Length (signal): 1.16 ft (0.355 m)
  • Cable Length (power): 5 ft (1.5 m)


  ELECTRICAL

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 200 W, 1.6 A @ 120 V, 60 Hz
  • Power and Current: 200 W, 0.87 A @ 230 V, 50 Hz


  CERTIFICATIONS / QUALIFICATIONS

  • CE, MET
  • IP Rating: IP65, outdoor/wet, with pressure equalizing M14 GORE valve
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
  • MET Listing Number: E114016-1144
  • US Safety: UL 8750
  • Canadian Safety: CSA C22.2 No. 250.13-12


  WHAT'S INCLUDED

  • ÉPIX Flex Boost
  • Seetronic Powerkon power cord


  REQUIRED ACCESSORIES

  • Accessories (required): ÉPIX Flex Drive
  • Compatible Mounting Options: M12 Bolt/Clamp


  OPTIONAL ACCESSORIES

  • Clamps
  • IP Flex Cables
  • Seetronic Powerkon cables
  • DMX Cables
