Chamsys GENETIX-GS8 - Eight-port unmanaged Gigabit PoE network switch

Roll over image to zoom in Click on image to zoom

Chamsys GENETIX-GS8 - Eight-port unmanaged Gigabit PoE network switch

Name: Chamsys GENETIX-GS8 - Eight-port unmanaged Gigabit PoE network switch
Brand: Chamsys
SKU: GENETIX-GS8
Price: 1249.99 CAD
Availability: InStock

ChamsysSKU: GENETIX-GS8

Price:

$1,249.99

Shipping calculated at checkout

Stock:

Available to order from our supplier!

Quantity:

Pay with Interac e-Transfer® at checkout

Share this product

GeNetix Switch 8 is an eight-port unmanaged Gigabit PoE network switch that provides a total output of up to 200W of Power over Ethernet across its 8 ports. Ports 1-4 support IEEE 802.3bt up to 100W per port. In modes A & B, all ports support 802.3af and 802.3at standards. This rack mountable switch features a rear PowerCon True1 Mains input connector and is also truss mountable via its M12 threaded insert.

Overview:

200w 8 port Unmanaged Gigabit PoE Network Switch
Supports Multiple PoE Specifications: Ports 1-4 802.3bt and on all ports 802.3af, 802.3at in Modes A & B
Ports 1-4 Support PoE++ (up to 100w per port), Ports 5-8 PoE+ (up to 30w per port) up to 200w switch limit
Locking Ethernet Connectors
PowerCon True1 Top Mains Input
Desktop or 19” Rack Mountable (1U)
M12 Threaded Insert for Clamp Mounting

GeNetix Nodes

GeNetix Nodes provide a solution for remote data distribution in a wide variety of applications. Supporting industry standard protocols like Art-Net, sACN, RDM along with advanced features including DMX Fallback, Merging and Scene Storage

Specifications

Hardware Specifications:

Network Ports: 8
Mains Input: PowerCon True1 Top
Port Status LEDs: Yes
802.3af and 802.3at in Modes A & B: Yes
802.3bt up to 100W per Port: Ports 1-4
Removable Rack Ears: Yes
Max Power Consumption (mains): 8.2w

Software Specifications:

Gigabit Ethernet: Yes
Unmanaged Network Switch: Yes

Included Accessories:

Neutrik powerCON TRUE1 Power Cable: 1

Node Weights and Dimensions:

Width (No Rack Ears): 330mm (12.99 inches)
Width (With Ears): 482mm (18.98 inches)
Depth: 172mm (6.77 inches)
Height: 43mm (1.69 inches)
Weight: 2.05 KG (4.52 lb)
