TASCAM CG-2000 - Jitter Management

Name: TASCAM CG-2000 - Jitter Management
Brand: TASCAM
SKU: CG-2000
Price: 7119.00 CAD
Availability: InStock

TASCAMSKU: CG-2000

Price:

$7,119.00

Shipping calculated at checkout

Stock:

Available to order from our supplier!

Quantity:

Pay with Interac e-Transfer® at checkout

Share this product

Video Sync/Master Clock Generator
• 0.01PPM word clock accuracy
• Video Clock Generator
• 12 word clock outputs, two with variable rates
• Redundant power supplies and clock source

Master Clock Generator

The best in the CG series for broadcasting stations and post-production sites

With redundancy of both the power supply and the video/audio clock, as well as many other functions, the CG-2000 meets the strict demands of broadcasting and post production.

Features at a glance

Two power supply circuits for redundancy [CG-2000 only]
Supports video reference/word clock redundancy [CG-2000 only]
Internal clock uses a high-precision OCXO (oven-controlled crystal oscillator) that is not influenced by the temperature of the environment
External input connector that supports 10MHz, allowing creation of systems with even higher precision
Jitter management circuit provides stable clock
Glitch-free relocking circuit prevents noise and skipping during clock dropouts and recovery
Numerous output connectors, including (12) word clock outputs, enabling the use in large-scale video/audio synchronization systems
Supports input and output of a variety of video signal formats, including NTSC, PAL and HD Tri-level
AES3 and AES11 signals can also be used for external master clock input sources
Analyzer function that can measure output device termination
Optimal levels can be provided to other devices by adjusting wordclock output levels
Error status can be outputted using GPO parallel output, allowing the monitoring of error occurrence
Self-calibration function using an external oscillator (Atomic/GPS 10MHz, GPS PPS)
*Use of the self-calibration function requires the use of a separate PPS-output 10MHz oscillator with a built-in GPS antenna.
Word clock performance up to 192 kHz
0.1% pull-up/down for 24F(Film) and 29.97F(NTSC), and 4% pull-up/down for 24F(Film) and 25F(PAL)
Up to (4) system settings can be saved to buttons for recall, and saved settings can be imported and exported via USB
Durable nut-coupling BNC connectors made by Amphenol
Independent circuit boards for each connector prevents contact failures due to twisting
Three-prong IEC power cable included
Panel-lock switch can be used to prevent inadvertent changes to unit operation
128x64-pixel organic EL display with a wide viewing angle
Firmware updates possible using the USB port
EIA 1U rack mount size
RoHS-compliant product

Spec description

	CG-2000	CG-1800	CG-1000
Inputs
VIDEO INPUTS
Connector	BNC × 2 (A/B)	BNC	–
Input level	0.5Vp-p to 2.0Vp-p		–
Input impedance	75Ω (ON/OFF selectable by menu)		–
Input signal
SD video black burst	NTSC (29.97), NTSC B/W (30), PAL (25)		–
HD video tri-level
720p	50, 59.97, 60		–
1080p	23.976, 24, 25, 29.97, 30, 59.94, 60		–
1080i/psf	23.976, 24, 25, 29.97, 30		–
Allowable frequency deviation	±10ppm		–
WORD/EXT INPUTS
Connector	BNC × 2 (A/B)	BNC
Input level	0.5Vp-p to 5.0Vp-p
Input impedance	75Ω/50Ω (75/50/OFF selectable by menu)
Supported frequencies
WORD CLOCK	32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192k Hz
ATOM	10.0MHz
GPS	10.0MHz
Allowable frequency deviation	±50ppm
AES3/11 INPUT
Connector	XLR-3-31(1: GND, 2: HOT, 3: COLD)
Input level	0.2Vp-p to 10Vp-p
Input impedance	110Ω
Format	AES11-2003, AES3-2003, IEC60958-4
Supported frequencies	32k / 44.1k / 48k / 88.2k / 96k / 76.4k / 92k Hz
Allowable frequency deviation	±50ppm
CALIBLATION INPUT
Connector	BNC
Input level	0.5 to 5.0 Vp-p
Input impedance	50Ω (ON/OFF selectable by menu)
Supported frequencies
ATOM	10.0MHz
GPS	10.0MHz, PPS
Outputs
VIDEO OUTPUTS
Connector	BNC × 4 (1-4)		–
Output impedance	75Ω		–
Output signal
SD video black burst	NTSC (29.97), NTSC B/W (30), PAL (25)		–
HD video tri-level
720p	50, 59.97, 60		–
1080p	23.976, 24, 25, 29.97, 30, 50, 59.94, 60		–
1080i/psf	23.976, 24, 25, 29.97, 30		–
WORD OUTPUTS
Connector	BNC × 12 (1-12)
Output level	1.0Vp-p to 3.5Vp-p (adjustable in 0.5V steps by menu)
Output impedance	75Ω
Supported frequencies	32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192k Hz ¼×Fs, ½×Fs, 1×Fs, 2×Fs, 4×Fs, 256×Fs (Only OUTPUTS 11-12)
AES3/11 OUTPUTS
Connector	XLR-3-31 (1: GND, 2: HOT, 3: COLD) × 2 (1-2)
Output level	2.5Vp-p
Output impedance	110Ω
Format	AES11-2003, AES3-2003, IEC60958-4
Supported frequencies	32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192k Hz
S/PDIF OUTPUTS
Connector	RCA Pin jacks × 2 (1-2)
Output level	0.5Vp-p
Output impedance	75Ω
Format	IEC60958-3
ALARM OUTPUT
Connector	6-pin Euroblock connector	–
Output level	Open collector	–
Transmission method	Parallel	–
Output impedance	10ohm	–
Withstand voltage	20V	–
Maximum current	35mA	–
USB	A data transfer use by a USB flash drive
Connector	USB B-type
Protocol	USB2.0 High Speed (480Mbps)
Power supply rating	DC5.0V, 0.2A
Internal oscillator performance
TYPE	OCXO
frequency accuracy	±0.01ppm (factory default value)
frequency stability	±0.005ppm / day
Power	AC100 - 240V, 50/60Hz
Power consumption	14W	11.5W	10W
Dimensions (W×H×D)	19.0%quot; × 1.77" × 12.2" / 483 × 45 × 310 mm
Weight	7.3 lbs. / 3.3 kg	7.1 lbs. / 3.2 kg	6.8 lbs. / 3.1 kg
Operating temperature range	32˚F to 104˚F / 0˚C to 40˚C
Included accessories	Power cords × 2, rackmounting screw kit, operation manual (with warranty)	Power cords, rackmounting screw kit, operation manual (with warranty)
