| System Type |
Two Way |
| Active or Passive |
Passive |
| Power Rating (Watts) |
400 |
| Biampable |
No |
| Nominal Impedance (Ohms) |
8 |
| Sensitivity (dB @1Watt/1m) |
98 |
| Max SPL (dB) |
124 |
| Frequency Response (Hz +/- 3dB) |
55 - 20k |
| Crossover Frequency (Hz) |
1100 |
| Driver Configuration |
12 inch / 1 inch |
| HF Driver(s) |
1 inch |
| HF Horn |
Rotatable ABS Waveguide |
| HF Dispersion (°H x °V) |
80 x 50 Rotatable |
| HF Protection |
CTL |
| Inputs - Speakon 4-pin |
2 |
| Inputs - Screw Terminal |
1 Pair |
| Flying Hardware |
1/4 inch |
| Optional Flying Hardware |
FH2W Flyware bracket is available |
| Pole Mount Adapter (1 3/8"-3.5cm) |
No |
| Enclosure Materials |
15mm (5/8inch) 11-ply Russian birch |
| Grille |
Perforated Metal |
| Covering / Finish |
Two Part White Epoxy |
| Other Details |
Has rear-mount rigging points for Omnimount 60.0WA Bracket |
| Dimensions (DWH xbackW, inches) |
14.3 x 16.2 x 24.1 x 11.1 |
| Dimensions (DWH xbackW, cm) |
36.3 x 41.1 x 61.2 x 28.2 |
| Weight (lbs/kg) |
54 / 24.6 |
