The Artist Elite® AE5100 large diaphragm cardioid condenser instrument microphone provides uncompromising sound quality for overheads, percussion, acoustic guitar, strings and other acoustic instruments. With rich, warm, accurate sound, the AE5100 also incorporates the most essential ingredients for quality live sound in a choir microphone. Its large-diaphragm capsule delivers accurate, natural response, while its low-profile design permits innovative placement options. With a lower profile than the large studio microphones to which it compares sonically, the AE5100 offers an outstanding performance-to-size ratio. With its low noise and smooth response, the AE5100 is ideal for recording, too.
Large-diaphragm capsule delivers accurate and natural response
Low-profile design permits innovative placement options previously unattainable with a large-diaphragm condenser
Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
Robust design for enduring dependability on the road
Includes isolation clamp for shock protection, secure mounting and easy positioning
Integral 80 Hz HPF switch and 10 dB pad
Microphones
Element
Fixed-charge back plate, permanently polarized condenser
Polar Pattern
Cardioid
Frequency Response
20-20,000 Hz
Low Frequency Roll Off
80 Hz, 12 dB/octave
Open Circuit Sensitivity
-36 dB (15.8 mV) re 1V at 1 Pa
Maximum Input Sound Level
148 dB SPL, 1 kHz at 1% T.H.D.; 158 dB SPL with 10 dB pad (nominal)
Noise
11 dB SPL
Dynamic Range
137 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
83 dB, 1 kHz at 1 Pa
Phantom Power Requirements
11-52V DC, 3.2 mA typical
Switches
High-pass filter; 10 dB pad (nominal)
Weight
5.0 oz (143 g)
Dimensions
5.85" (148.5 mm) long, 1.02" (26.0 mm) maximum diameter
Output Connector
Integral 3-pin XLRM-type
Accessories Included
AT8471 isolation clamp for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; AT8136 windscreen; soft protective pouch
Audio-Technica Case Style
S4
